Operating weight (kg)
Rated power (kW)

Utilities

Heavy infrastructure

Quarries & Aggregates
ENGINE SYSTEM: Weichai engine,high-pressure common rail, supercharged intercooling, three-stage fuel filtration, strong power, energy-saving and efficient.
COMFORTABLE CABIN:Newly upgraded H series cab with beautiful appearance, wide view and comfortable driving experience. The rocker switch has a variety of functions and a reasonable layout. New instrument panel, human-machine interaction interface is vivid, the whole machine status information is simple and obvious.
ADVANCED VIBRATION SYSTEM:Vibrating wheel adopts through-axis design, amplitude is stable and consistent,good compaction performance.
ROBUST STRUCTURES: Front and rear frame articulated connection, high reliability, small turning radius. Internationally famous brand drive axle, large driving force, smooth running, superior performance and long service life.
EASY MAINTENANCE: Engine filter is centrally located on one side for easy maintenance; The engine hood is equipped with an electric actuator, which can be opened and closed with one key, a large opening and closing angle for easy maintenance; Fuse control box centrally arranged, easy to do maintenance and repair; Air conditioning filter is outside mounted, easy to remove and clean.
| Operating weight (kg) | 10000 |
| Rated power (kW) | 82 |
| Compaction width (mm) | 2130 |
| Overall dimension(L×W×H)(mm) | 5555×2298×3150 |
| Excitation force (kN) | 245/139 |
| Fuel tank capacity(L) | 230 |
