Operating Weight (kg)
Rated Power (kW)
Bucket capacity (m³)

Utilities

Heavy infrastructure

Quarries & Aggregates
Powerful And Adaptable
215kW high-power engine with excellent fuel adaptability.
Premium And Reliable
Equipped with full electronic control positive flow hydraulic system, enlarged radiator, reinforced large chassis, heavy-duty structural components & frame, and three-stage fuel filtration system.
Safety And Comfort
The H-Series ROPS Cab comes standard with a comprehensive safety protection system, ergonomic air suspension seat with seat heating function, an intuitive touchscreen IECU.
| Operating Weight (kg) | 35200 |
| Engine Model | BFM8-29T2 |
| Rated Power (kW) | 215 |
| Bucket capacity (m³) | 2.0 |
| Length×Width×Height (mm) | 11000×3190×3600 |
| Emission Standard | GB 20891-2007 StageⅡ |
| Swing Speed (r/min) | 10.7 |
| Traveling Speed (km/h) | 3.0/5.0 |
| Max. Digging Radius (mm) | 10360 |
| Max. Digging Depth (mm) | 6680 |
| Max. Digging Height (mm) | 9900 |
| Fuel Tank Capacity (L) | 590 |
