Rated Load (kg)
Standard Bucket Capacity (m³)
Operating Weight (kg)
Rated Power (kW)

Utilities

Heavy infrastructure

Quarries & Aggregates
High Efficiency: WEI CHAI Engine Tier 2. The energy-saving engine fits well with the high-efficiency and realizes a comprehensive energy saving of more than 10%.High market share and high reliability; Low maintenance cost.
High Reliability: SDLG planetary transmission, F2/R1, Hydraulic power shift. Simple operation, high transmission efficiency. After years of market validation, long service life. Adjusted the gearbox reduction ratio to improve the traveling speed and V-loading efficiency.
Heavy-Duty: SDLG special reinforced drive axle. Main transmission and wheel deceleration transmission ratio optimization, to increased reliability by more than 60%. Stable and reliable performance, convenient operation and maintenance.
Comfortability: New designed H-series cabin .The visibility, the accessibility of function switch , the comfortability and the sealability of cabin has improved significantly.
| Rated Load (kg) | 5000 |
| Length×Width×Height (mm) | 8000×3024×3423 |
| Wheel Base (mm) | 3000 |
| Max.Dumping Height (mm) | 3130 |
| Dumping Distance (mm) | 1220 |
| Steering Angel (°) | 35 |
| Emission Standard | GB 20891-2007 |
| Max.Tractive Force (kN) | 152 |
| Max.Breakout Force (kN) | ≥175 |
| Fuel Tank Capacity (L) | 260 |
| Standard Bucket Capacity (m³) | 2.8 |
| Operating Weight (kg) | 16900 |
| Rated Power (kW) | 162 |
| Engine Model | Wechai WD10G220E21 |
