Rated Load (kg)
Standard Bucket Capacity (m³)
Operating Weight (kg)
Rated Power (kW)

Utilities

Heavy infrastructure

Quarries & Aggregates
Engine and torque converter match well,vehicle accelerate quickly,high working efficiency.
Tipping load, breakout force, traction, lifting force are ahead of competitor, the vehicle is stable with high working ability.
Low fuel consumption per unit time, short cycle time, high comprehensive efficiency .
Large cab, good vision, low noise, low vibration, AC refrigeration fast, good driving experience, low fatigue strength
Beautiful appearance, the old machine is easy to deal with, second-hand salvage value is high.
| Rated Load (kg) | 5300 |
| Length×Width×Height (mm) | 8250*3024*3466 |
| Wheel Base (mm) | 3300 |
| Max.Dumping Height (mm) | 3100 |
| Dumping Distance (mm) | 1210 |
| Steering Angel (°) | 36 |
| Emission Standard | Tier II (GB20891-2007) |
| Max.Tractive Force (kN) | 155 |
| Max.Breakout Force (kN) | ≥175 |
| Fuel Tank Capacity (L) | 280 |
| Standard Bucket Capacity (m³) | 3 |
| Operating Weight (kg) | 17080 |
| Rated Power (kW) | 162 |
| Engine Model | Wechai WD10G220E23 |
